Opel Astra H 1.9 CDTI Mappack (150HP Z19DTH, Bosch EDC16C9 ECU) is developed for tuners who need a complete and clearly structured WinOLS project.
It provides a reliable base for Stage 1, Stage 2 and Stage 3 calibrations – from mild economy/performance upgrades to advanced hardware builds.
🔧 Included maps (main categories):
-
Driver Request & Torque Control:
-
Driver Wish (Normal & Sport modes)
-
Torque Limiters (general, by gear, by RPM, by oil/fuel temperature)
-
NM to IQ Conversion
-
Gear-dependent torque limiters (1st to 6th gear)
-
-
Injection & Fuel:
-
Multiple SOI (Start of Injection) Maps (SOI 1–5)
-
SOI “B” Variants (DPF regeneration-related, if applicable)
-
Duration Maps
-
Duration “B” Variants (DPF regeneration-related, if applicable)
-
IQ Limiters (RPM, coolant/fuel temperature)
-
Fuel temperature-based IQ limiter
-
-
Rail Pressure (Fuel System):
-
Rail Pressure Maps
-
Rail Pressure Limiters (incl. temperature-dependent)
-
Rail Pressure Sensor Calibration
-
-
Turbo & Boost Control:
-
N75 Maps (turbo actuator control)
-
Boost Pressure Limiters (incl. by atmospheric pressure)
-
SVBL (Single Value Boost Limiter)
-
Boost Maps and Control Strategies
-
-
Emissions & Smoke Control:
-
EGR Maps (standard & temperature-based)
-
EGR Hysteresis
-
Smoke Limiter by Lambda
-
💡 Key Advantages:
✔️ Covers both Normal and Sport driving modes
✔️ Includes DPF-related SOI/Duration variants (“B” maps) where applicable
✔️ Clean, professional, and structured for WinOLS
✔️ Suitable for Stage 1, Stage 2 and Stage 3 tuning
✔️ Solid base for economy, performance, and advanced hardware upgrade projects
⚠️ Note: This product contains only the structured Mappack. Original or modified binary files are not included. For professional use only.
